Renault F4R - Page 716

16A-5
STARTING - CHARGING
Alternator: Removal - Refitting
K4M
16A
a Refit:
-the alternator strut bolt on the cylinder block,
-the alternator strut bolt on the alternator.
a Tighten to torque:
-the alternator strut bolt on the alternator (25
N.m),
-the alternator strut bolt on the cylinder block
(25 N.m).
a Position the wiring on the alternator.
a Attach the connector to the alternator.
a Refit the wiring on the alternator positive terminal.
a Torque tighten the nut for the positive terminal of
the alternator (21 N.m).
III - FINAL OPERATION
a Fit the front end panel.
a Refit:
-the upper bolts on the front end panel,
-the lower bolts on the front end panel,
-the upper clips on the front end panel.
a Clip the hoses on the cooling fan assembly.
a Refit:
-the engine wiring channel on the cooling fan as-
sembly,
-the bonnet catch (see Bonnet latch: Removal -
Refitting) (52A, Non-side opening element mecha-
nisms),
-the front impact cross member (see Front impact
cross member: Removal - Refitting) (41A, Front
lower structure),
-the audible warning (see Horn: Removal - Refit-
ting) (82B, Horn),
-the front bumper mountings (see Front bumper
support: Removal - Refitting) (42A, Front upper
structure),
-the headlights (see Front headlight: Removal -
Refitting) (80B, Headlights),
- the air deflectors,
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection).
a Refit the oil filter (see 10A, Engine and cylinder
block assembly, Oil filter: Removal - Refitting,
page 10A-48) .
a Connect the connector of the air temperature sensor
on the intake manifold.
a Refit:
- the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
- the engine undertray.
a Refit:
- the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
- the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres).
a Refit:
- the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
- the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
a Refit the engine cover.
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
K4M, and 858 or 866
K4M, and 858 or 866
K4M, and 848
K4M, and 858 or 866
K4M, and 848
