16A-19
STARTING - CHARGING
Starter: Removal - Refitting
K9K
16A
REFITTING
I - REFITTING PREPARATION OPERATION
a When replacing the starter, remove the starter pro-
tective shield.
a Refit the starter protective shield on a new starter.
a Check that the starter centring dowel is in place.
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit the starter.
a Torque tighten the starter bolts (44 N.m).
III - FINAL OPERATION
a Fit the starter wiring.
a Tighten to torque:
-the starter supply terminal nut (8 N.m).
-the nut on the starter solenoid (5 N.m).
a Connect:
-the oil level sensor connector,
-the oil pressure sensor connector.
a Refit the intercooler air outlet pipe (see 12B, Turbo-
charging, Intercooler air outlet pipe: Removal -
Refitting, page 12B-56) .
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
a Refit:
-the engine undertray,
-the engine cover.
