10A-68
ENGINE AND CYLINDER BLOCK ASSEMBLY
Oil pressure sensor: Removal - Refitting
F9Q
10A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Remove:
-the engine undertray bolts,
-the engine undertray.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the oil pressure sensor connector (1) .
a Remove the oil pressure sensor (2) .
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Refit the oil pressure sensor.
a Torque tighten the oil pressure sensor (35 Nm).
a Connect the oil pressure sensor connector.
II - FINAL OPERATION
a Refit the engine undertray.
Tightening torquesm
oil pressure sensor 35 Nm
135653
135654
