19A-85
COOLING
Water pump inlet pipe: Removal - Refitting
K4M
19A
a Using the (Mot. 1202-02) or (Mot. 1202-01) or (Mot.
1448) remove:
-the heater matrix hose clip (9) ,
-the cooling radiator bottom hose clip (10) .
a Disconnect the following from the coolant pump inlet
pipe:
-the heater matrix hose,
-the cooling radiator bottom hose.
a Remove:
- the bolts (11) and (12) from the coolant pump inlet
pipe,
- the coolant pump inlet pipe.
K4M, and 858 or 866
136576
136572
136577
