19D-9
ENGINE MOUNTING
Left-hand suspended engine mounting: Removal - Refitting
K9K
19D
-the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment).
a Remove:
-the upper engine tie-bar bolts (2) ,
-the upper engine tie-bar,
a Unclip the battery wiring channel from the left-hand
suspended engine mounting (3) .
a Remove the battery wiring channel from the left-
hand suspended engine mounting.
a Fit the tool (Ms. 583) (4) onto the clutch master cy-
linder supply hose.
a Disconnect the hydraulic clutch pipe from the clutch
master cylinder by pulling on the clip (5) .
K9K, and 832
134221
135506
134486
