19D-10
ENGINE MOUNTING
Left-hand suspended engine mounting: Removal - Refitting
K9K
19D
a Disconnect the hydraulic clutch pipe from the hy-
draulic clutch release bearing by pulling on the clips
(6) .
a Fit suitable blanking plugs on:
-the opening of the hydraulic clutch release bearing,
-the openings of the hydraulic clutch pipe,
-the opening of the clutch master cylinder.
a Unclip the hydraulic clutch pipe from the left-hand
suspended engine mounting at (7) .
135470
K9K, and 832
135469
