PG-FP5 CHAPTER 4 PROGRAMMING GUI USAGE
R20UT0008EJ0400 Rev. 4.00 Page 69 of 240
Jul 15, 2010
[Reset option of Run after Disconnect]
When the [Run after Disconnect] function in the [Command options] area of the Device setup dialog
[Advanced] tab is enabled, the properties of the RESET
¯¯¯¯¯¯
signal after the write command is completed can be
set to Pull-up or Hi-Z. The default is Hi-Z.
[Change the PASSWORD] button
Clicking the [Change the PASSWORD] button will open the following dialog box.
Figure 4-38 Password setting Dialog Box
This dialog box allows the user to change the registered password.
Input the current password into the [OLD PASSWORD] box, input the new password into the [NEW
PASSWORD] box and [Confirm PASSWORD] box, and then click OK . When Cancel is clicked, the
dialog box will be closed and the password will not be changed.
[INIT] button
Resets the FP5 to its default settings. Initializing the FP5 will reset or delete the following stored information.
• Password
• FP5 Manager setting
• PR5 file
• ESF file
• Program file
To Next Page
