350-12245-01 – updated December, 2019 QuadView UHDx/UHDx KVM User Guide 53
C H A P T E R 4
C o m m a n d L i n e C o n t r o l
Input Label
Background Color
(continued)
ATM 09 INP_BCC W 6 ~09 INP_BCC W 6 Sets input label background
color to blue.
ATM 09 INP_BCC W 7 ~09 INP_BCC W 7 Sets input label background
color to yellow.
Restore Default Setting ATM 08 RST_SET W ~08 RST_SET W Resets all settings, including
network settings, to their factory-
default values. Use with caution.
Report Baud Rate ATM 08 BAU_RAT R ~BAU_RAT [1...5] Reports current baud rate
setting.
Example: Baud Rate = 9600
ATM 08 BAU_RAT R
~BAU_RAT 1
Set Baud Rate ATM 09 BAU_RAT W 1 ~09 BAU_RAT W 1 Sets serial baud rate to 9600.
ATM 09 BAU_RAT W 2 ~09 BAU_RAT W 2 Sets serial baud rate to 19200.
ATM 09 BAU_RAT W 3 ~09 BAU_RAT W 3 Sets serial baud rate to 38400.
ATM 09 BAU_RAT W 4 ~09 BAU_RAT W 4 Sets serial baud rate to 57600.
ATM 09 BAU_RAT W 5 ~09 BAU_RAT W 5 Sets serial baud rate to 115200.
Miscellaneous ATM 08 CSW_VER R [Firmware version] Reports QuadView UHDx
firmware version.
ATM 09 SYS_UPT W 1 ~09 SYS_UPT W 1 Updates QuadView UHDx
firmware using file stored on
connected USB storage device.
ATM 08 WIN_LIS R (refer to examples) Reports window status (on/off),
source, origin, width, and height.
Examples:
Two-window layout:
ATM 08 WIN_LIS R
WinA1:On Input:1 0000 0000 3840 2160
WinB1:On Input:2 0000 1440 1280 0720
WinA2:Off
WinB2:Off
Four-window layout:
ATM 08 WIN_LIS R
WinA1:On Input:1 0000 0001 1920 1080
WinB1:On Input:2 1920 0001 1920 1080
WinA2:On Input:3 0000 1080 1920 1080
WinB2:On Input:4 1920 1080 1920 1080
Report Key Lock
Status
ATM 08 KEY_LOK R ~KEY_LOK [0...2] Reports current Key Lock
setting.
Example: Key Lock off
ATM 08 KEY_LOK R
~KEY_LOK 0
Table 4-5 Advanced Commands (Continued)
Function Command Feedback Description
To Next Page
