Service Tables
SM 49 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
003
Memory Lock
Disabled
Not used
IPFAX Port Settings
001 H323 Port Sets the H323 port number.
002 SIP Port Sets the SIP port number.
003 RAS Port Sets the RAS port number.
004 Gatekeeper port Sets the Gatekeeper port number.
005 T.38 Port Sets the T.38 port number.
006 SIP Server Port Sets the SIP port number.
107
007
IPFAX Protocol
Priority
Select "H323" or "SIP".
FAX SW
201
001 – 032 00 – 1F
4.2.4 SP4-XXX (ROM VERSIONS)
4
Mode No. Function
101 001 FCU ROM Version Displays the FCU ROM version.
102 001 Error Codes Displays the latest 64 fax error codes.
103 001 G3-1 ROM Version Displays the G3-1 modem version.
4.2.5 SP5-XXX (INITIALIZING)
5
Mode No. Function
101 Initialize SRAM (except Secure)
