Ricoh Aficio MP C2050 Service Manual

Jam Detection
SM Appendix 7-5 D037/D038/D040/D041
Appendix:
Jam
Detection
Jam Code
SP
Display Description
LCD
Display
7504 248 Belt Lift Solenoid
The mainframe detects the belt lift
solenoid error from the internal finisher.
R1, R2
7504 249 Finisher Fan
The mainframe detects the finisher fan
error from the internal finisher.
R1, R2
7504 250 Punch Motor
The mainframe detects the lock signal
from the punch motor.
R1, R2
7504 251 Finisher Proof Exit
The mainframe detects the lock signal
from the registration motor of the punch
unit.
R1, R2
7504 252
FIN:Stapler Position
Error
The stapler unit stays on the jogger end
fence so that stapling is disabled.
R1, R2
7504 253 FIN:Job Data Error
Unexpected job data is sent to the
internal finisher from the mainframe.
R1, R2
 The jam location display depends on where a paper jam is detected at power-on.
ARDF (Original Jam)
Jam Code
SP
Display Description
LCD
Display
7505 1 At Power On Original is stack at power-on. P
7505 3 Skew Correction: ON
Skew correction sensor does not detect
paper.
P
7505 4 Registration: ON
Registration sensor does not detect
paper.
P
7505 5 Paper Exit: ON Exit Sensor does not detect paper. P
7505 53 Skew Correction: OFF Skew correction sensor does not turn P
