Controller Options
SM 2-99 D037/D038/D040/D041
Installaion
Make sure that “Admin. Authentication” is ON.
[System Settings] – [Administrator Tools] – [Administrator Authentication Management]
- [Admin. Authentication]
If this setting is OFF, tell the customer this setting must be ON before you do the
installation procedure.
3. Make sure that “Administrator Tools” is enabled (selected).
[System Settings] – [Administrator Tools] – [Administrator Authentication Management]
- [Available Settings]
If this setting is disabled (not selected), tell the customer this setting must be enabled
(selected) before you do the installation procedure.
Seal Check and Removal
You must check the box seals to
make sure that they were not
removed after the items were sealed
in the box at the factory before you do
the install.
1. Check the box seals [A] on each corner of the box.
Make sure that a tape is attached to each corner.
The surfaces of the tapes must be blank. If you see “VOID” on the tapes, do not
install the components in the box.
2. If the surfaces of the tapes do not show “VOID”, remove them from the corners of the
box.
3. You can see the “VOID” marks [B] when you remove each seal. In this condition, they
cannot be attached to the box again.
Installation Procedure
Unplug the main machine power cord before you do the following procedure.
You must install the DataOverwriteSecurity unit in SD Card slot 1. However, the
Postscript option and others are also installed in SD Card slot 1. You must do the
"SD Card Appli Move" procedure first if you want to install the Data Overwrite
Security unit.
Rev. 02/2009
