Page #341 background imageLoading...
Page #341 background image
Address Book Upload/Download
SM 5-29 D037/D038/D040/D041
System
Maintenance
Reference
5.9.3 UPLOAD
1. Turn off the main power switch of the main machine.
2. Remove the SD slot cover at the left rear side of the machine ( x 1).
3. Install the SD card, which has already been uploaded, into the SD card slot 2.
4. Turn on the main power switch.
5. Enter the SP mode.
6. Do SP5-846-052 (Restore All Addr Book).
7. Exit the SP mode, and then turn off the main power switch.
8. Remove the SD card form the SD card slot 2.
9. Install the SD slot cover.
 The counter in the user code information is initialized after uploading.
 The information of an administrator and supervisor cannot be downloaded nor
uploaded.
 If there is no data of address book information in the SD card, an error message is
displayed.
