Maintenance Tables
SM Appendix 3-3 D037/D038/D040/D041
Appendix:
Preventive
Maintenance
Tables
Item 60K 120K 240K EM Remarks
Vertical Transport Sensor C Dry cloth
By-pass Feed Roller C Damp cloth
By-pass Friction Pad C Dry cloth
By-pass HP Sensor C Dry cloth
Duplex
Duplex Transport Roller C Damp cloth
Duplex Exit Sensor C Dry cloth
Paper Exit
Paper Exit Roller Damp cloth
Inverter Roller C Damp cloth
Inverter Relay Roller C Damp cloth
Inverter Sensor C Dry cloth
Fusing Exit Sensor C Dry cloth
*1: The registration roller requires a cleaning maintenance every 60 K (total count).
ARDF (D366)
Item 120K EM Remarks
Sensors C Blower brush
Platen Sheet Cover C
Damp cloth; alcohol (Replace if
required.)
White Plate C Dry or damp cloth
Drive Gear L Grease G501
Transport Roller C Damp cloth; alcohol

Table of Contents

Other manuals for Ricoh Aficio MP C2050

Preview: Operating Instructions
Operating Instructions328 pages
Preview: User Manual
User Manual41 pages
Preview: Specification
Specification8 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C2050 and is the answer not in the manual?

Ricoh Aficio MP C2050 Specifications

Ricoh Aficio MP C2050

General Specifications IconGeneral Specifications
output speed20 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed20 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)

Ricoh Aficio MP C2550

General Specifications IconGeneral Specifications
output speed25 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed25 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)
