Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-1 D037/D038/D040/D041
Appendix:
SP Mode
Tables
9. APPENDIX: SP MODE TABLES
9.1 SYSTEM SERVICE MODE
9.1.1 SERVICE MODE TABLE
SP1-XXX (Feed)
[Leading Edge Registration] Leading Edge Registration Adjustment
(Tray Location, Paper Type, Color Mode), Paper Type -> Plain, Thick 1, Thick
2 or Thick3
1001
Adjusts the leading edge registration by changing the registration motor
operation timing for each mode.
001 Tray:Plain:600dpi *ENG
002 Tray:Thick1:600dpi *ENG
003 Tray:M-Thick:600dpi *ENG
004 By-pass:Plain:600dpi *ENG
005 By-pass:Thick1:600dpi *ENG
006 By-pass:Thick2:600dpi *ENG
007 By-pass:Thick3:600dpi *ENG
008 By-pass: M-Thick:600dpi *ENG
009 Duplex:Plain:600dpi *ENG
010 Duplex:M-Thick:600dpi *ENG
[–9 to 9 / 0.0 / 0.1 mm/step]
011 Tray:Plain:1200dpi *ENG
012 Tray:Thick1:1200dpi *ENG
013 Tray:M-Thick:1200dpi *ENG
014 By-pass:Plain:1200dpi *ENG
[–9 to 9 / 0.0 / 0.1 mm/step]
⇒
⇒
⇒
Rev. 12/2008
