Process Control Error Conditions
SM Appendix 5-5 D037/D038/D040/D041
Appendix:
Process
Control Error
Conditions
No. Result Description Possible Causes/Action
"Voffset
Threshold"
(SP3-324-004)
 Defective BCU
1. Replace the ID sensors.
2. Check the connection.
3. Replace the BCU board.
9
Vsg
Adjustment
error
Vsg adjustment
has not been
completed.
 Other cases
Retry SP3-321-010.
5.1.3 LINE POSITION ADJUSTMENT RESULT
SP2-194-010 to -012 (Line Position Adjustment Result: M, C, Y)
This SP shows the number as a line position adjustment result on the LCD. It shows which
color has an error (M, Y or C).
No. Result Description Note
0 Not done Line position adjustment has not been done. -
1
Completed
successfully
Line position adjustment has correctly been
done,
-
2
Cannot detect
patterns
ID sensors have not detected the patterns for
line position adjustment.
See Note
3
Fewer lines on
the pattern than
the target
The patterns, which ID sensors have detected,
are not enough for line position adjustment.
See Note
4
More lines on
the pattern than
the target
Not used in this machine. -
5-9 Not used - -
 For details, see the "Troubleshooting Guide - Line Position Adjustment" section.
