Ricoh Aficio MP C2050 Service Manual

Optional Equipment
D037/D038/D040/D041 1-22 SM Appendix
Capacity: 500 sheets
Paper Weight: 80 g/m
2
(21 lb.)
Paper Size: A3 SEF to A5, DLT SEF to HLT
Power Source: DC 24V, 5V (from the main frame)
Power Consumption: 58 W
Dimensions (W x D x H): 550 mm x 520 mm x 137 mm (22" x 20.8" x 5.48")
Weight: Less than 12 kg (26.4 lbs)
1.6.3 PAPER FEED UNIT (D331)
Paper Size: A5 to A3, 5
1
/
2
" x 8
1
/
2
" SEF to 11" x 17"
Paper Weight: 60 - 105 g/m
2
, 16 - 28 lb
Tray Capacity: 500 sheets (80 g/m
2
, 20 lb) x 2 trays
Paper Feed System: Feed roller and friction pad
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Power Source:
 24 Vdc and 5Vdc (from the copier/printer)
 120 Vac (120 V version) from the copier/printer when the
optional tray heater is installed
 220 – 240 Vac (230 V version) from the copier/printer
when the optional tray heater is installed
Power Consumption: 35 W (Copying/printing)
Weight: 25 kg (55 lb)
Size (W x D x H): 550 mm x 520 mm x 271 mm

Ricoh Aficio MP C2050 Specifications
