Bit Switches
D432/D433 66 SM
4.3.2 I-FAX SWITCHES
I-fax Switch 00 [SP No. 1-102-001]
FUNCTION COMMENTS
No
Original Width of TX
Attachment File
This setting sets the maximum size of the original
that the destination can receive. (Bits 3~7 are
reserved for future use or not used.)
0 A4
1 B4
2 A3
3-6 Reserved
7
Not used
0: Off (not selected), 1: On (selected)
If more than one of these three bits is set to “1”,
the larger size has priority. For example, if both Bit
2 and Bit 1 are set to “1” then the maximum size is
“A3” (Bit 2).
When mail is sent, there is no negotiation with the
receiving machine at the destination, so the
sending machine cannot make a selection for the
receiving capabilities (original width setting) of the
receiving machine. The original width selected
with this switch is used as the RX machine’s
original width setting, and the original is reduced to
this size before sending. The default is A4.
If the width selected with this switch is higher than
the receiving machine can accept, the machine
detects this and this causes an error.
I-fax Switch 01 [SP No. 1-102-002]
FUNCTION COMMENTS
No
Original Line Resolution of TX
Attachment File
These settings set the maximum resolution of the
original that the destination can receive.
0 200x100 Standard
1 200x200 Detail
2 200x400 Fine
0: Not selected
1: Selected
If more than one of these three bits is set to “1”,
the higher resolution has priority. For example, if
