Bit Switches
SM 67 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
3 300 x 300 Reserve
4 400 x 400 Super Fine
5 600 x 600 Reserve
6 Reserve
both Bit 0 and Bit 2 are set to “1” then the
resolution is set for "Bit 2 200 x 400.
mm/inch
7
This setting selects mm/inch conversion for mail transmission.
0: Off (No conversion), 1: On (Conversion)
When on (set to “1”), the machine converts millimeters to inches for sending mail.
There is no switch for converting inches to millimeters.
Unlike G3 fax transmissions which can negotiate between sender and receiver to
determine the setting, mail cannot negotiate between terminals; the mm/inch
selection is determined by the sender fax.
When this switch is Off (0):
Images scanned in inches are sent in inches.
Images scanned in mm are sent in mm.
Images received in inches are transmitted in inches.
Images received in mm are transmitted in mm.
When this switch is On (1):
Images scanned in inches are sent in inches.
Images scanned in mm are converted to inches.
Images received in inches are transmitted in inches.
Images received in mm are converted to inches.
I-fax Switch 02 [SP No. 1-102-003]
No FUNCTION COMMENTS
RX Text Mail Header Processing
0
This setting determines whether the header information is printed with text e-mails
when they are received.
0: Prints only text mail.
1: Prints mail header information attached to text mail.
When a text mail is received with this switch On (1), the “From” address and
