Ricoh Aficio MP C2050 Service Manual

Optional Equipment
SM Appendix 1-21 D037/D038/D040/D041
Appendix:
Specifications
1.6 OPTIONAL EQUIPMENT
1.6.1 ARDF (D366: STANDARD FOR H-MODELS (D038/D041))
Size A3 to A5, DLT to HLT
Simplex
Weight 40 to 128 g/m
2
(10 to 34 lb.)
Size A3 to A5, DLT to HLT
Paper Size/Weight:
Duplex
Weight 52 to 105 g/m
2
(14 to 28 lb.)
Table Capacity: 50 sheets (80 g/m
2
, 20 lb)
Original Standard Position: Rear left corner
Separation: Feed belt and separation roller
Original Transport: Roller transport
Original Feed Order: From the top original
Copy - 32 to 200 %
Color 32.6 to 200 %
Supported Magnification
Ratios:
Fax
Black & white 48.9 to 200 %
Power Source: DC 24V, 5V from the scanner unit
Power Consumption: 50 W or less
Dimensions (W × D × H): 550 mm x 491 mm x 120 mm (21.7" x 19.3" x 4.7")
Weight: 10 kg (22 lb.)
1.6.2 PAPER FEED UNIT (D425)
Paper Feed System: FRR
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)

Ricoh Aficio MP C2050 Specifications
