PM Parts Settings
D037/D038/D040/D041 3-2 SM
3.2 PM PARTS SETTINGS
3.2.1 BEFORE REMOVING THE OLD PM PARTS
1. Enter the SP mode.
2. Output the SMC logging data with SP5-990-004.
3. Set the following SPs to "1" before you turn the power off. Then, the machine will reset
the PM counters automatically. In the case of developer, the developer initialization will
also be done automatically.
4. Exit the SP mode.
Item SP
Development Unit
Black: 3902-001
Cyan: 3902-002
Magenta: 3902-003
Yellow: 3902-004
Drum Unit
Black: 3902-009
Cyan: 3902-010
Magenta: 3902-011
Yellow: 3902-012
ITB Unit 3902-013
Fusing Unit 3902-014
Fusing Roller 3902-015
Fusing Belt 3902-016
ITB Cleaning Unit 3902-017
PTR Unit 3902-018
PCDU Toner Collection Bottle 3902-019*
1
ITB Toner Collection Bottle 3902-020*
1
