Bit Switches
SM 85 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
(DIS/NSF) before transmission.
1-5
Not used
Do not change the factory settings.
6-7
Available unit of resolution in
which fax messages are
received
Bit 7: 0, Bit 6: 0 = mm
Bit 7: 0, Bit 6: 1 = inch
Bit 7: 1, Bit 6: 0 = mm and inch
(default)
Bit 7: 1, Bit 6: 1 = Not used
For the best performance, do not change the
factory settings.
The setting determined by these bits is informed to
the transmitting terminal in the pre-message
protocol exchange (in the DIS/NSF frames).
Communication Switch 15 – Not used (do not change the settings)
Communication Switch 16 [SP No. 1-104-023]
No FUNCTION COMMENTS
0-7
Not used
Do not change the factory settings.
Communication Switch 17 [SP No. 1-104-024]
No FUNCTION COMMENTS
0
SEP reception
0: Disabled
1: Enabled
0: Polling transmission to another maker’s
machine using the SEP (Selective Polling) signal
is disabled.
1
SUB reception
0: Disabled
1: Enabled
0: Confidential reception to another maker’s
machine using the SUB (Sub-address) signal is
disabled.
2
PWD reception
0: Disabled
1: Enabled
0: Disables features that require PWD (Password)
signal reception.
3-6
Not used
Do not change the factory settings.
