Service RAM Addresses
D432/D433 134 SM
Bit 6: Network error display 0: Displayed, 1: Not displayed
Bit 7: Transmit error mail notification 0: Enabled, 1: Disabled
6800E6(H) - User parameter switch 22 (SWUSR_16)
(This switch is not printed on the user parameter list.)
Bit 0: Dial tone detection (PSTN 1) 0: Disabled, 1: Enabled
Bits 1 to 3: Not used
Bits 4 to 7: Destination Reentered Count (0 -15) (See chart ☛)
6800E7(H) – User parameter switch 23 (SWUSR_17): Not used
6800E8(H) - User parameter switch 24 (SWUSR_18): Not used
6800E9(H) - User parameter switch 25 (SWUSR_19)
Bit 0: Not used
Bit 1: Reception mode switch timer 0: Off, 1: On (switching Fax or Fax/Tel)
Bit 2: Mode priority switch 0: Fax first, 1: Tel first
Bit 3: Dial in function (Japan Only)
Bit 4: RDS operation 0: Not acceptable, 1: Acceptable for the limit specified by system
switch 03
 This bit is only effective when RDS operation can be selected by the user
(see system switch 02).
Bits 5 to 7: Not used
6800EA(H) - 6800EB(H) - User parameter switches 26 - 27 (SWUSR_1A - 1B): Not used
6800EC(H) - User parameter switch 28(SWUSR_1C)
Xxxxx
6800ED(H) - User parameter switch 29(SWUSR_1D)
xxxxxx
6800EE(H) and 6800EF(H) - User parameter switches 30 and 31 (SWUSR_1E and 1F):
Not used
6800F0(H) - User parameter switch 32 (SWUSR_20)
Bit 0: Quotation priority for a destination when there is no destination of the specified type
0: Paper output priority = Priority order: 1. IP-fax destination, 2. Fax Number, 3. E-mail
address, 4. Folder
1: Electric putout order = Priority order: 1. E-mail address, 2. Folder, 3. IP-fax destination, 4.
Fax number
Bits 1 to 7: Not used
6800F1(H) - User parameter switch 33 (SWUSR_21): Not used
6800F2(H) - User parameter switch 34 (SWUSR_22)
Reentered Count
7 6 5 4 Count
0 0 0 0 0
0 0 0 1 1
0 0 1 0 2
.
.
.
1 1 1 1 15
⇒
⇒
Rev. 12/2008
