Scanner Test Mode
SM 6-13 D037/D038/D040/D041
Trouble-
shooting
3. Abnormal power supply
•The required voltage is not supplied to the devices.
4. Overheat/overcooling
 The environment is inappropriate for the board (the scanner unit).
5. Static electricity
 Static electricity of a high voltage occurs during the test.
6. Others
 The scanner and i-controller are incorrectly connected.
When you have completed a check, turn the main switch off and on before you do another
check. When you have completed all necessary checks, turn the main switch off and
on.Error! No index entries found.
