Ricoh Aficio MP C2050 Service Manual

SC Tables
SM Appendix 4-11 D037/D038/D040/D041
Appendix:
Service Call
Conditions
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE ON error: Y
The PFGATE ON signal does not assert within 5 seconds after
processing the image in normal job or MUSIC (line position adjustment)
for start position [Y].
232 D
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE OFF error: Y
 The PFGATE ON signal still asserts within 5 seconds after
processing the image in normal job or MUSIC (line position
adjustment) for end position [Y].
 The PFGATE ON signal still asserts when the next job starts.
233 D
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE ON error: M
The PFGATE ON signal does not assert within 5 seconds after
processing the image in normal job or MUSIC (line position adjustment)
for start position [M].
234 D
See SC 230 for troubleshooting details.
