Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-17 D037/D038/D040/D041
Appendix:
SP Mode
Tables
026
Control Time 1 Duplex 226
Center Temp.3:MThick:-226
ENG
027
Control Time 2 Duplex 226
Ends Temp.3:MThick:-226
ENG
[-10 to 10 / -5 / 1 deg/step]
028 Center Temp.4:MThick:-226 ENG
029 Ends Temp.4:MThick:-226 ENG
030 Center Temp.1:Other:226- ENG
031 Ends Temp.1:Other:226- ENG
032 Center Temp.2:Other:226- ENG
033 Ends Temp.2:Other:226- ENG
034 Center Temp.3:Other:-226 ENG
[-10 to 10 / 0 / 1 deg/step]
035 Ends Temp.3:Other:-226 ENG
[-10 to 10 / -5 / 1 deg/step]
036 Center Temp.4:Other:-226 ENG
037 Ends Temp.4:Other:-226 ENG
[-10 to 10 / 0 / 1 deg/step]
1117 [Idling Time After Heater OFF]
After Ready ENG
[0 to 4 / 4 / 1 sec/step] DFU
001
Specifies the idling time without the lamp on after reaching the ready
temperature.
After Job End ENG
[0 to 4 / 0 / 1 sec/step]
002
Specifies the idling time without the lamp on after job end.
This idling prevents the heating roller overheating after job end.
1118 [Curl Temp Correction]
001 Operation Pattern *ENG
[0 to 3 / 0 / 1]
