Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-19 D037/D038/D040/D041
Appendix:
SP Mode
Tables
013 OHP: Center *ENG
014 OHP: Ends *ENG
[0 to 100 / 40 / 1 %]
015 SP 1: Center *ENG
016 SP 1: Ends *ENG
017 SP 2: Center *ENG
018 SP 2: Ends *ENG
[0 to 100 / 70 / 1 %]
019 SP 3:: Center *ENG
020 SP 3: Ends *ENG
[0 to 100 / 60 / 1 %]
021 Envir. Correct:Low *ENG
[-100 to 100 / 10 / 1 %]
022 Envir. Correct:High *ENG
023 Envir. Correct: Center *ENG
024 FF Correct:Ends *ENG
[-100 to 100 / 0 / 1 %]
[FF Correct Time]
025 FF Correct Time *ENG
[0 to 60 / 0 / 1 sec]
[FF Control thresh]
026 Offset:Center *ENG
027 Offset:Ends *ENG
[0 to 50 / 25 / 1 deg]
[FF Start Time]
028 Fgate Timer:FC:Full *ENG
[0 to 10000 / 1900 / 1msec]
029 Fgate Timer:BW:Full *ENG
[0 to 10000 / 5300 / 100msec]
030 Fgate Timer:BW:Full *ENG
[0 to 10000 / 0 / 100msec]
031 Fgate Timer:BW:Half *ENG
[0 to 10000 / 400 / 100msec]
[FF Correct Time]
