Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-33 D037/D038/D040/D041
Appendix:
SP Mode
Tables
17: Band (Horizontal)
18: Band (Vertical)
19: Checker Flag Pattern
20: Grayscale Vertical Margin
21: Grayscale Horizontal Margin
23: Full Dot Pattern
005 Color Selection -
Specifies the color for the test pattern.
[1 to 4 / 1 / 1/step]
1: All colors, 2: Magenta, 3: Yellow, 4:
Cyan
006 Density: Bk -
007 Density: C -
008 Density: M -
009 Density: Y -
Specifies the color density for the test
pattern.
[0 to 15 / 15 / 1 /step]
0: Lightest density
15: Darkest density
2111 [Line Pos. Ajust]
001 Execute: Mode a -
Executes the fine line position adjustment
twice.
If this SP is not completed (NG is
displayed), do SP2111-003 first and then try
this SP again.
002 Execute:Mode b -
Executes the fine line position adjustment
once.
If this SP is not completed, do SP2111-003
first and then try this SP again.
003 Execute:Mode c -
Executes the rough line position adjustment
once.
After doing this SP, make sure to execute
SP2111-001 or -002. Otherwise, the line
position adjustment is not perfectly done.
