Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-37 D037/D038/D040/D041
Appendix:
SP Mode
Tables
[P-Sensor Test] DFU
2145
Displays the minimum result 2 values of the ID sensor check.
Bk, M, C, Y: ID sensors for the process control
Front, Center, Rear: ID sensors for the automatic line position adjustment
001 Minimum 2 *ENG
[TM-Sensor Test] DFU
005 Minimum 2: Front *ENG
006 Minimum 2: Center *ENG
007 Minimum 2: Rear *ENG
[0 to 5.5 / 0 / 0.01V/step]
[Area Mag. Correction] LD Pulse Area Correction (Color, Area) FA
2150
Adjusts the magnification for each area. The main scan (297 mm) is divided
into 8 areas. Area 1 is at the front side of the machine (left side of the image)
and area 8 is at the rear side of the machine (right side of the image).
Decreasing a value makes the image shift to the left side on the print.
Increasing a value makes the image shift to the right side on the print.
1 pulse = 1/16 dot
027 Bk: Area0 *ENG
[-256 to 255 / 0 / 1sub-dot/step]
028 Bk: Area1 *ENG
029 Bk: Area2 *ENG
030 Bk: Area3 *ENG
031 Bk: Area4 *ENG
032 Bk: Area5 *ENG
033 Bk: Area6 *ENG
034 Bk: Area7 *ENG
035 Bk: Area8 *ENG
Adjusts the area magnification for LD 0.
[–256 to 255 / 0 / 1 sub-dot/step ]
