Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-39 D037/D038/D040/D041
Appendix:
SP Mode
Tables
188 Y: Area5 *ENG
189 Y: Area6 *ENG
190 Y: Area7 *ENG
191 Y: Area8 *ENG
[Shading Correct Setting] FA
2152
Adjusts the area correction value for each LD power.
The main scan is divided into 16 areas. However, the image areas are limited
from area 1 to area 14.
For BK and Magenta, area 1 is at the rear side of the machine (left side of the
image) and area 14 is at the front side of the machine (right side of the image).
For Cyan and Yellow, area 1 is at the front side of the machine (right side of the
image) and area 14 is at the rear side of the machine (left side of the image).
001 Bk: Area 0 *ENG
002 Bk: Area 1 *ENG
003 Bk: Area 2 *ENG
004 Bk: Area 3 *ENG
005 Bk: Area 4 *ENG
006 Bk: Area 5 *ENG
007 Bk: Area 6 *ENG
008 Bk: Area 7 *ENG
009 Bk: Area 8 *ENG
010 Bk: Area 9 *ENG
011 Bk: Area 10 *ENG
012 Bk: Area 11 *ENG
013 Bk: Area 12 *ENG
This is for the synchronizing detection
board.
[50 to 150 / 100 / 1 %/step]
