System Service Mode
D037/D038/D040/D041 9-48 SM Appendix
011 S. Scan Cor. Setting *ENG
DFU
[0 or 1 / 0 / 1 boolean /step]
0: Adjusted with Bk
1: Adjusted in minimum shift
among four colors
2191
[MUSIC Coeff Setting] Line Position Adjustment: Coefficient Setting DFU
ch 0: ID sensor at rear, ch 1: ID sensor at center, ch 2: ID sensor at front
001 ch 0: Filter: Front: a1 *ENG
[–131071 to 131071 / 125869 / 1 bit/step]
002 ch 0: Filter: Front: a2 *ENG
[–131071 to 131071 / –60488 / 1 bit/step]
003 ch 0: Filter: Front: b0 *ENG
[–131071 to 131071 / 39 / 1 bit/step]
004 ch 0: Filter: Front: b1 *ENG
[–131071 to 131071 / 77 / 1 bit/step]
005 ch 0: Filter: Front: b2 *ENG
[–131071 to 131071 / 39 / 1 bit/step]
006 ch 0: Filter: Rear: a1 *ENG
[–131071 to 131071 / 128596 / 1 bit/step]
007 ch 0: Filter: Rear: a2 *ENG
[–131071 to 131071 / –63398 / 1 bit/step]
008 ch 0: Filter: Rear: b0 *ENG
[–131071 to 131071 / 84 / 1 bit/step]
009 ch 0: Filter: Rear: b1 *ENG
[–131071 to 131071 / 168 / 1 bit/step]
010 ch 0: Filter: Rear: b2 *ENG
[–131071 to 131071 / 84 / 1 bit/step]
011 ch 1: Filter: Front: a1 *ENG
[–131071 to 131071 / 125869 / 1 bit/step]
012 ch 1: Filter: Front: a2 *ENG
[–131071 to 131071 / –60488 / 1 bit/step]
013 ch 1: Filter: Front: b0 *ENG
[–131071 to 131071 / 39 / 1 bit/step]
014 ch 1: Filter: Front: b1 *ENG
[–131071 to 131071 / 77 / 1 bit/step]
015 ch 1: Filter: Front: b2 *ENG
[–131071 to 131071 / 39 / 1 bit/step]
016 ch 1: Filter: Rear: a1 *ENG
[–131071 to 131071 / 128596 / 1 bit/step]
017 ch 1: Filter: Rear: a2 *ENG
[–131071 to 131071 / –63398 / 1 bit/step]
