Ricoh Aficio MP C2050 Service Manual

System Service Mode
D037/D038/D040/D041 9-194 SM Appendix
011 TRAY 3: 3 *ENG
[0 or 1 / 0 (EU/ASIA), 1 (NA) / - ]
0: B4, 1: LG
012 TRAY 3: 4 *ENG
[0 or 1 / 0 (EU/ASIA), 1 (NA) / - ]
0: B5 LEF, 1: Exe LEF
013 TRAY 4: 1 *ENG
[0 to 2 / 0 (EU/ASIA), 1 (NA) / - ]
0: A4LEF, 1: LTLEF
014 TRAY 4: 2 *ENG
[0 or 1 / 0 (EU/ASIA), 1 (NA) / - ]
0: A3, 1: DLT
015 TRAY 4: 3 *ENG
[0 or 1 / 0 (EU/ASIA), 1 (NA) / - ]
0: B4, 1: LG
016 TRAY 4: 4 *ENG
[0 or 1 / 0 (EU/ASIA), 1 (NA) / - ]
0: B5 LEF, 1: Exe LEF
[RK 4 Disconnect Operation]
5186
Enables or disables the prevention for RK4 (accounting device) disconnection.
If the RK4 is disconnected for 10 seconds when this SP is set to "1 (Enable)",
the machine automatically jams a sheet of paper and stops.
001 - *ENG
[0 or 1 / 0 / 1/step]
0: Disable
1: Enable
[Copy NV Version]
5188
Displays the version number of the NVRAM on the controller board.
001 - - -
5195 [Limitless SW] DFU
001 - - -
