System Service Mode
SM Appendix 9-235 D037/D038/D040/D041
Appendix:
SP Mode
Tables
5846 [UCS Settings]
*CTL -
Machine ID (For Delivery Server) Displays ID
001
Displays the unique device ID in use by the delivery server directory. The
value is only displayed and cannot be changed. This ID is created from the
NIC MAC or IEEE 1394 EUI. The ID is displayed as either 6-byle or 8-byte
binary.
Machine ID Clear (For Delivery Server) Clears ID
002
Clears the unique ID of the device used as the name in the file transfer
directory. Execute this SP if the connection of the device to the delivery
server is unstable. After clearing the ID, the ID will be established again
automatically by cycling the machine off and on.
Maximum Entries
[2000 to 20000/ 2000 /1 /step]
003
Changes the maximum number of entries that UCS can handle.
If a value smaller than the present value is set, the UCS managed data is
cleared, and the data (excluding user code information) is displayed.
Delivery Server Retry Timer
[0 to 255 / 0 / 1 /step]
006
Sets the interval for retry attempts when the delivery server fails to acquire
the delivery server address book.
Delivery Server Retry Times
[0 to 255 / 0 / 1 /step]
007
Sets the number of retry attempts when the delivery server fails to acquire
the delivery server address book.
Delivery Server Maximum Entries
[2000 to 50000 / 2000 / 1/step]
008
Sets the maximum number account entries of the delivery server user
information managed by UCS.
LDAP Search Timeout
[1 to 255 / 60 / 1 /step]
010
Sets the length of the timeout for the search of the LDAP server.
040 Addr Book Migration (SD => HDD)
