Page #774 background imageLoading...
Page #774 background image
System Service Mode
D037/D038/D040/D041 9-240 SM Appendix
Setting
100
Repository: Download Image
Max. Size
Specifies the max size of the image data that
the machine can download.
[1 to 1024 / 1024 / 1 MB /step]
210 Setting: LogType: Job1
211 Setting: LogType: Job2
212 Setting: LogType: Access
213 Setting: Primary Srv
214 Setting: Secondary Srv
215 Setting: Start Time
216 Setting: Interval Time
217 Setting: Timing
NIA
5849 [Installation Date]
*CTL -
5849 1 Display
The “Counter Clear Day” has been changed
to “Installation Date” or “Inst. Date”.
5849 2 Switch to Print
Determines whether the installation date is
printed on the printout for the total counter.
[0 or 1 / 1 / - ]
0: OFF (No Print)
1: ON (Print)
003 Total Counter -
[Bluetooth Mode]
5851
Sets the operation mode for the Bluetooth Unit. Press either key.
[0:Public] [1: Private]

Table of Contents

Other manuals for Ricoh Aficio MP C2050

Preview: Operating Instructions
Operating Instructions328 pages
Preview: User Manual
User Manual41 pages
Preview: Specification
Specification8 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio MP C2050 and is the answer not in the manual?

Ricoh Aficio MP C2050 Specifications

Ricoh Aficio MP C2050

General Specifications IconGeneral Specifications
output speed20 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed20 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)

Ricoh Aficio MP C2550

General Specifications IconGeneral Specifications
output speed25 ppm BW & Full-Color
warm-up time25 seconds
first copy time full-color9.5 seconds
copy resolution600 x 600 dpi
original capacity50 sheets
dimensions23.1" x 25.8" x 33.3" (587 x 655 x 845 mm)
weight220 lbs
power requirements120V, 60Hz, 12A
Printer Controller IconPrinter Controller
cpuRM7035C @ 533MHz
memory768 MB (512 MB + 256 MB) RAM (Standard); 1GB RAM (Maximum)
max. print speed25 ppm BW & Full-Color
max. print resolution1200 x 1200 dpi
standard interfaces10Base-T/100Base-TX Ethernet (RJ-45), USB 2.0 Device, USB 2.0 Host I/F
Scanner Specifications IconScanner Specifications
scanner resolutionFrom 100 to 600 dpi (1200 dpi for TWAIN)
scanning speed bw41 ipm
scanning speed full-color26 ipm
scan area main scan11.7" (297mm)
scan area sub scan17" (432mm)
