Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-255 D037/D038/D040/D041
Appendix:
SP Mode
Tables
Displays the number of jams according to the location where jams were
detected.
NOTE: The LCT is counted as the 3rd feed station.
001 At Power On *CTL
003 Tray 1: ON *CTL
004 Tray 2: ON *CTL
005 Tray 3: ON *CTL
006 Tray 4: ON *CTL
008 Bypass: ON *CTL
009 Duplex: ON *CTL
011 Vertical Transport 1: ON *CTL
012 Vertical Transport 2: ON *CTL
017 Registration: ON *CTL
018 Fusing Entrance: ON *CTL
019 Fusing Exit: ON *CTL
020 Paper Exit: ON *CTL
021 Relay Exit: ON *CTL
022 Relay Transport: ON *CTL
025 Duplex Exit: ON *CTL
026 Duplex Reverse: ON *CTL
027 Duplex Entrance: ON *CTL
For details,  the "Jam
Detection" in the Appendix
Jam Detection.
028 1 Bin Exit Sensor *CTL
051 SEF Sensor 1 *CTL
052 SEF Sensor 2 *CTL
For details,  the "Jam
Detection" in the Appendix
Jam Detection.
