Page #798 background imageLoading...
Page #798 background image
System Service Mode
D037/D038/D040/D041 9-264 SM Appendix
101 Page (%): Developer: M
102 Page (%): Developer: Y
103 Page (%): ITB Unit
104 Page (%): ITB Cleaning Unit
105 Page (%): Fusing Unit
106 Page (%): Fusing Roller
107 Page (%): Fusing Belt
108 Page (%): PTR Unit
7804 [PM Counter Reset] PM Counter Clear
(Unit, [Color])
Clears the PM counter.
Press the Enter key after the machine asks “Execute?”, which will store the
PM counter value in SP7-906 (PM Counter - Previous) and reset the value of
the current PM counter (SP7-803) to “0”.
001 Paper
002 PCU: Bk
003 PCU: C
004 PCU: M
005 PCU: Y
006 PCU: All
007 Development Unit: Bk
008 Development Unit: C
009 Development Unit: M
010 Development Unit: Y
