Ricoh Aficio MP C2050 Service Manual

System Service Mode
SM Appendix 9-331 D037/D038/D040/D041
Appendix:
SP Mode
Tables
8 851 14 0 to 2%: C 8 851 34 5 to 7%: C
8 851 21 3 to 4%: BK 8 851 41 8 to 10%: BK
8 851 22 3 to 4%: Y 8 851 42 8 to 10%: Y
8 851 23 3 to 4%: M 8 851 43 8 to 10%: M
8 851 24 3 to 4%: C 8 851 44 8 to 10%: C
Coverage Count: 11-20% *CTL
[0 to 9999999/ 0 / 1]
8 861
These SPs display the number of scanned sheets on which the coverage
of each color is from 11% to 20%.
8 861 1 BK
8 861 2 Y
8 861 3 M
8 861 4 C
Coverage Count: 21-30% *CTL
[0 to 9999999/ 0 / 1]
8 871
These SPs display the number of scanned sheets on which the coverage
of each color is from 21% to 30%.
8 871 1 BK
8 871 2 Y
8 871 3 M
8 871 4 C
Coverage Count: 31%- *CTL
[0 to 9999999/ 0 / 1]
8 881
These SPs display the number of scanned sheets on which the coverage
of each color is 31% or higher.
