System Service Mode
SM Appendix 9-337 D037/D038/D040/D041
Appendix:
SP Mode
Tables
Copier
Reading
5803 Description
0 1
5803 1 C-Dev. Mtr:LOCK Normal Lock
5803 2 C-Drum Mtr:LOCK Normal Lock
5803 3 Bk-Drum/Dev. Mtr:LOCK Normal Lock
5803 4 ITB Mtr:LOCK Normal Lock
5803 5 Fusing/P-Exit Mtr:LOCK Normal Lock
5803 6 Electrical FAN:LOCK Normal Lock
5803 7 Fusing Fan:LOCK Normal Lock
5803 8 Dev. Front Fan:LOCK Normal Lock
5803 9 Dev. Rear Fan:LOCK Normal Lock
5803 10 Fusing Exit Fan:LOCK Normal Lock
5803 11 LD Unit FAN:LOCK Normal Lock
5803 12 Jun. Gate SOL Fan:LOCK Normal Lock
5803 13 Fusing:New Detection New Not new
5803 14 Fusing:Area Detection - -
5803 15 Zero Cross Not detected Detected
5803 16 Regist Sensor Paper detected No paper detected
5803 17 Drum Phase Sn:Bk
Actuator not
detected
Actuator detected
5803 18 Drum Phase Sn:Color
Actuator not
detected
Actuator detected
