System Service Mode
SM Appendix 9-343 D037/D038/D040/D041
Appendix:
SP Mode
Tables
6120 26 Relay Sensor Paper not detected Paper detected
6120 27 Tray Lower Sensor Lower Not lower
6120 28 Jogger HP Sensor Not HP HP
6120 29 Punch HP Sensor Not rear Rear Position
6120 30 Stapler Safety Sensor No staple Staple detected
6120 31 Staple Empty Sensor No staple Staple detected
6120 32 Punch Unit Sensor Not set Set
Table 1: Paper Size Switch (Tray 1/ 2)
Switch 1 is used for tray set detection.
0: Pushed, 1: Not pushed
Models Bit
North America Europe/Asia 2 1 0
11" x 17" SEF*
1
(A3 SEF)
A3 SEF*
1
(11" x 17" SEF)
1 0 0
8.5" x 14" SEF
*2
(B4 SEF)
B4 SEF
*2
(8.5" x 14" SEF)
0 0 0
A4 SEF A4 SEF 0 1 1
8.5" x 11" SEF 8.5" x 11" SEF 1 1 1
B5 SEF B5 SEF 1 1 0
11" x 81/2" LEF*
3
(A4 LEF)
A4 LEF*
3
(11" x 81/2" LEF)
0 0 1
10.5" x 7.25" LEF*
4
(B5 LEF)
B5 LEF*
4
(10.5" x 7.25" LEF)
0 1 0
A5 LEF A5 LEF 1 0 1
