System Service Mode
D037/D038/D040/D041 9-354 SM Appendix
6008 11 Junction Gate Solenoid -
6008 12 Stamp Solenoid Stamp Solenoid
9.1.4 TEST PATTERN PRINTING
Printing Test pattern: SP2-109
Some of these test patterns are used for copy image adjustments but most are used
primarily for design testing.
 Do not operate the machine until the test pattern is printed out completely.
Otherwise, an SC occurs.
1. Enter the SP mode and select SP2-109-003.
2. Enter the number for the test pattern that you want to print and press [#].
3. When you want to select the single color of Magenta, Yellow or Cyan for printing a test
pattern, select the color with SP2-109-005 (2: Magenta, 3: Yellow, 4: Cyan).
4. When you want to change the density of printing a test pattern, select the density with
SP2-109-006 to -009 for each color.
 If you select "0" with SP2-109-006 to -009, the color to be adjusted to "0" does
not come up on a test pattern.
5. When you are prompted to confirm your selection, touch "Yes" to select the test pattern
for printing.
6. Touch "Copy Window" to open the copy window, then select the settings for the test
print (paper size etc.).
 If you want to use black and white printing, touch "Black & White" on the LCD. If
you want to use color printing, touch "Full Colour" on the LCD.
7. Press the "Start" key to start the test print.
8. After checking the test pattern, touch "SP Mode" on the LCD to return to the SP mode
display.
9. Reset all settings to the default values.
10. Touch "Exit" twice to exit SP mode.
