No. Description Q’ty
6
Joint bracket (Front center) (only for the
optional paper feed unit)
1
7 Joint bracket (Rear) 4
8
Joint bracket (Frame) (only for optional paper
feed unit)
1
9 M3 x 6: Screw 11
10 M3 x 12: Screw 1
11 Tapping screw 3
Installation Procedure
• Unplug the machine power cord before starting the following procedure.
• Do the following procedure not to damage any harnesses.
•
Check that harnesses are not damaged or pinched after installation.
Anti-condensation Heater (Optional Unit)
109
