Put the machine near the power source with the clearance shown above.
Machine Dimensions
[A]: 621 mm [D]: 150 mm
[B]: 540 mm [E]: 505 mm
[C]: 150 mm [F]: 498 mm
Power Requirements
• Insert the plug firmly in the outlet.
•
Do not use an outlet extension plug or cord.
•
Ground the machine.
1. Input voltage level:
• 110 V, 60 Hz More than 10 A
• 120 to 127 V, 60 Hz: More than 10 A
Installation Requirements
