Ricoh AFICIO MP C305SP Field Service Manual

• The NVRAM [B] on the old controller board should be transferred to the new controller
board. Insert the NVRAM with the notch on the NVRAM pointing upward.
Controller Board DIMM
1. Rear cover ( p.177)
2. Release the lock levers of the DIMM socket at both ends, then remove the DIMM [A].
BICU
1. Rear cover ( p.177)
4. Replacement and Adjustment
300
