4. Disconnect seven connectors from the PSU ( x 7).
5. Remove three screws ( x 3).
6. Release the harnesses from the clamp ( x 1).
7. PSU [A]
Toner Bottle ID Contact Sensor
1. HVPS (C, B) ( p.306)
Electrical Components
303
