4. ARDF open / close sensor (Hook x 3, x 1)
Carriage Unit HP Sensor
1. ARDF ( p.315)
2. Scanner front cover ( p.186 "Scanner Unit")
3. Scanner upper cover ( p.188 "ARDF Cover Open / Close Sensor")
Scanner
189
