Ricoh AFICIO MP C305SP - Toner Supply Motors (CMYK)

2. Move the rear right handle [A] out of the way, so that it does not interfere with the removal
procedures ( x 3).
3. Move the harness guide [A] out of the way, so that it does not interfere with the removal
procedures ( x 3, x 1).
4. Fusing motor [A] ( x 4)
Toner Supply Motors (CMYK)
1. Toner bottle ID contact sensor ( p.303)
4. Replacement and Adjustment
