3. Exhaust fan [A] ( x 2, x 1)
• Install the exhaust fan with its engraved mark facing the outside of the machine.
• Make sure that the engraved mark on the exhaust fan faces the outside of the machine when
replacing it.
Temperature / Humidity Sensor
1. Front lower cover ( p.172 "Front Cover")
2. Temperature / humidity sensor [A] ( x 1, x 1)
4. Replacement and Adjustment
314
