• Make sure that you do not release the exit roller drive belt [A] ([B] in step 2) by mistake when
removing the paper exit unit. If the belt is released and dropped down to the lower part of the
machine, you will have difficulty in reattaching it.
Paper Exit Sensor
1. Paper exit unit ( p.281)
2. Sensor bracket [A] ( x 1, x 1)
Paper Exit
283
