Ricoh AFICIO MP C305SP - Main SP Tables-6; SP6-XXX (Peripherals)

Main SP Tables-6
SP6-XXX (Peripherals)
6006 [ADF Adjustment]
001 Face *ENG Adjusts the side-to-side and leading
registration of originals with the ARDF.
[-2.0 to 2.0 / 0.0 / 0.1mm/step ]
002 Side-to-Side *ENG
003 Leading Edge Duplex Front *ENG Adjusts the side-to-side and leading
registration of originals with the ARDF.
[-5.0 to 5.0 / 0.0 / 0.1mm/step ]
004 Leading Edge Duplex Rear *ENG
007 Rear Edge Erase *ENG
Adjusts the erase margin at the original
trailing edge.
[-5.0 to 5.0 / 0.0 / 0.1mm/step ]
6007
[ADF INPUT Check]
Displays the signals received from the sensors and switches of the ARDF. Only Bit 0 is used
for ADF input check.
009 Original Detection *ENG [0 or 1 / 0 / 1/step ]
013 Registration Sensor *ENG [0 or 1 / 0 / 1/step ]
015 Feed Cover *ENG [0 or 1 / 0 / 1/step ]
6008
[ADF OUTPUT Check]
Activates the electrical components for functional check.
It is not possible to activate more than one component at the same time.
003 Paper Feed Motor Rotating *ENG [0 or 1 / 0 / 1/step ]
004 Paper Feed Motor Counter-rotating *ENG [0 or 1 / 0 / 1/step ]
009 Paper Feed Solenoid *ENG [0 or 1 / 0 / 1/step ]
011 Paper Feed Reverse Solenoid *ENG [0 or 1 / 0 / 1/step ]
