5803 16 Vertical Transport Sensor Paper detected Paper not detected
5803 17 Bypass Paper Size Sensor Paper detected Paper not detected
5803 18 Toner End Sensor: Y Toner end Toner remaining
5803 19 Toner End Sensor: C Toner end Toner remaining
5803 20 Toner End Sensor: M Toner end Toner remaining
5803 21 Toner End Sensor: K Toner end Toner remaining
5803 22 Drum Phase Sensor: K
Actuator not
detected
Actuator detected
5803 23 Drum Phase Sensor: CMY
Actuator not
detected
Actuator detected
5803 24 Interlock SW 1 Front door open Front door closed
5803 25 Interlock SW 2 Front door open Front door closed
5803 26 Right Door Sensor Closed Open
5803 30 Duplex Cover Sensor Closed Open
5803 31 LDU Shutter Sensor Closed Open
5803 32 Waste Toner Bottle Set Sensor Set Not set
5803 33 Waste Toner Bottle Full Sensor Not full Full
5803 34 ITB Unit: New Not new New
5803 35 Fusing Fan: Lock Normal Lock
5803 36 Fusing Fan 1: Lock Normal Lock
5803 37 Fusing Fan 2: Lock Normal Lock
5803 38 Fusing Front Fan: Lock Normal Lock
5803 40 Toner Supply Fan: Lock Normal Lock
5803 41 Drive Unit Fan: Lock Normal Lock
5803 43 Ventilation Fan 1: Lock Normal Lock
5803 44 Ventilation Fan 2: Lock Normal Lock
3. SP Mode Tables
434
