1902
[Drum Phase Adj.]
-
001 Execute ENG
[- / - / -]
[Execute]
1907
[Paper Feed Timing Adj.]
Adjusts the timing of paper feed. (A "+" setting broadens paper feed interval, a “-”
setting narrows paper feed interval.)
001 Tray1 Clutch ON: Plain *ENG [-10 to 10 / 0 / 1mm/step]
002 Tray1 Clutch ON: Middle Thick *ENG [-10 to 10 / 0 / 1mm/step]
003 Tray1 Clutch ON: Thick *ENG [-10 to 10 / 0 / 1mm/step]
007 Tray1 Clutch OFF: Plain *ENG [-10 to 10 / 0 / 1mm/step]
008 Tray1 Clutch OFF: Middle Thick *ENG [-10 to 10 / 0 / 1mm/step]
009 Tray1 Clutch OFF: Thick *ENG [-10 to 10 / 0 / 1mm/step]
010 Tray1 Paper Sensor: Plain *ENG [-10 to 10 / 0 / 1mm/step]
011 Tray1 Paper Sensor: Middle Thick *ENG [-10 to 10 / 0 / 1mm/step]
012 Tray1 Paper Sensor: Thick *ENG [-10 to 10 / 0 / 1mm/step]
013 By-pass Clutch ON: Plain *ENG [-10 to 10 / 0 / 1mm/step]
014 By-pass Clutch ON: Middle Thick *ENG [-10 to 10 / 0 / 1mm/step]
015 By-pass Clutch ON: Thick *ENG [-10 to 10 / 0 / 1mm/step]
016 By-pass Clutch ON: Envelop *ENG [-10 to 10 / 0 / 1mm/step]
017 By-pass Clutch OFF: Plain *ENG [-10 to 10 / 0 / 1mm/step]
018 By-pass Clutch OFF: Middle Thick *ENG [-10 to 10 / 0 / 1mm/step]
019 By-pass Clutch OFF: Thick *ENG [-10 to 10 / 0 / 1mm/step]
020 By-pass Clutch OFF: Envelop *ENG [-10 to 10 / 0 / 1mm/step]
021 ExitPaperDivergence SOL:OFF *ENG [-20 to 20 / 0 / 1mm/step]
022 ExitPaperDivergence SOL:ON *ENG [-20 to 20 / 0 / 1mm/step]
3. SP Mode Tables
70
